Stock #  15450

HUSTLER Raptor XDX-54"

Dealer Price $6,699 USD
All serialized products are subject to destination and setup fees.
In Stock Locations: 1 Gatesville 5 Springtown 3 Weatherford Not available at your location? No Problem, we will transfer it to your nearest location. On checkout, please indicate which location is closest for you.
Overview

The Raptor® XDX is at the top of Hustler's residential zero-turn category. It has commercial-grade features like a 10-gauge fabricated deck, cast steel deck hangers, vented and tool-less removable pulley covers, and reaches up to 8mph with Hydro-Gear® ZT-3100® commercial transmissions. The 5-inch-deep deck is designed to allow for mowing through thick grass at top speeds. The heavy-duty XDX is backed by a 3yr / 300hr limited warranty and 1yr / 300hr commercial limited warranty.

  • 21.5hp, 23hp & 24hp Kawasaki Engines
  • 48", 54" & 60” decks
  • Up to 8 mph mowing speed
  • 3-year / 300 hour limited warranty
Specifications
Model
Raptor XDX
Category Name
Zero Turn Mowers
Sale Type
New
Manufacturer
Hustler Turf
deck
SPINDLES
Aluminum with 1" shaft and double lip sealed ball bearings
DECK LIFT
Foot Operated
DECK DEPTH
5.0"
BLADE LENGTH
18.50"
CUTTING WIDTH
54"
DECK MATERIAL
Fabricated 11 gauge steel
CUTTING HEIGHT
1.5" to 4.5"
SPINDLE MOUNTS
Reinforced 7 gauge steel
BLADE TIP SPEED
18,900
DECK ENGAGEMENT
Ogura GT1.5
IMPACT TRIM AREA
3/8" x 1" steel bar
NUMBER OF BLADES
3
engine
COOLING
Air Cooled
DISPLACEMENT
726cc
ENGINE WARRANTY
3 Year Warranty
ENGINE HORSEPOWER
23
ENGINE MANUFACTURER
Kawasaki FR691
general
SEAT
Bolstered extra high-back seat with armrests and built-in lumbar support
CUP HOLDER
features

HUSTLER Raptor XDX 54

1
Welded Steel Deck
Welded fabricated steel deck helps add durability and can extend the mower's life.

2
Wider Stance
Designed to provide ample room adding to the comfort for the operator.

3
SmoothTrak Steering
Precision control designed to help trim and maneuver easily around obstacles.

4
Bolstered Seat
Helps provide a comfortable ride with armrests and airflow to the back.

5
Rubber Floor Mat
Helps provide comfort by minimizing vibration on the operator's feet. Standard on all Raptor models.

6
Fabricated Frame
Continuous one-piece 1½ inch by 3 inch welded tubular frame.

7
Foot-Operated Deck Lift
Easily adjust the deck height between 1.5" - 4.5".

8
Easy to Service
Flip-up seat pan, removable floor pan, vented pulley covers.

9
Exclusive BigBite Rear Tires
We worked directly with the tire manufacturer on this design.

10
Kawasaki® Power
Powered by a V-Twin Kawasaki® Engine.

key specs
WARRANTY
3 Year/300 hour residential or 1 Year/300 hour commercial
DRIVE TIRE
22 x 11-10 BigBite™
FRONT TIRE
13 x 6.5
TRANSMISSION
Hydro-Gear ZT-3100®
CUTTING WIDTH
54"
FUEL CAPACITY
3 gal.
CUTTING HEIGHT
1.5" to 4.5"
ENGINE HORSEPOWER
23
GROUND SPEED (FWD)
Up to 8 mph
ENGINE MANUFACTURER
Kawasaki FR691
dimensions
WEIGHT (LBS)
678
HEIGHT (INCHES)
43.7
LENGTH (INCHES)
71.1
DRIVE TIRE (INCHES)
22 x 11-10 BigBite™
FRONT TIRE (INCHES)
13 x 6.5
WIDTH W/ CHUTE UP (INCHES)
57
TIRE-TO-TIRE WIDTH (INCHES)
48.6
PRODUCTIVITY (ACRES PER HOUR)
3.49
literature

Name

Link

Brochure PDF Download
Extra Fields
ProductSerialNumber
24032132
construction
FRAME
1.5" X 3.0" steel tubing
FRONT AXLE
Fabricated with sealed ball bearings
FRONT CASTER FORK
Fabricated 3/8" steel
FRONT CASTER WHEEL
Sealed ball bearings
drive system
TYPE
Dual Hydrostatic
TRANSMISSION
Hydro-Gear ZT-3100®
FUEL CAPACITY
3 gal.
PARKING BRAKE
Integrated with steering levers
GROUND SPEED (FWD)
Up to 8 mph
dimensions with catcher
CATCHER STYLE
2-bag
CATCHER CAPACITY
7.2 bushel
POWERED / NON-POWERED
Non-powered
MOWER WIDTH W/ CATCHER
63.2
MOWER LENGTH W/ CATCHER
92.3
